HSI-CHIN ELECTRONICS .,CO LTD.

MATERIAL & FINISHES

	INSULATOR: PBT UL 94-V0 RATED
	CONTACT: COPPER ALLOY
	SHELL: STEEL
	HOOD: STEEL
	CONTACT PLATING: SELECTIVE GOLD OVER NICKEL PLATED
	SHELL PLATING: NICKEL OVER COPPER PLATED

ELECTRICAL CHARACTERISTICS

	RATING CURRENT: 1 AMP
	CONTACT RESISTANCE: 25 MILLIOHM MAX.
	INSULATION RESISTANCE: 1000 MEGOHM MIN. AT 500V
	DIELECTRIC VOLTAGE: 1000V AT 1 MINUTE
	OPERATING TEMPERATURE: -55 TO +105
	MATING CYCLES: 3000 CYCLES MIN.
